FAG NU305-E-XL-M1 Single Row Cylindrical Bearing
FAG NU305-E-XL-M1 Single Row Cylindrical Bearing
| Brand: FAG |
FAG
Schaeffler Technologies AG & Co. KG, also known as Schaeffler Group, is a German manufacturer of rolling element bearings for automotive, aerospace and industrial uses. It was founded in 1946 by brothers Dr. Wilhelm and Dr.-Ing. E. h. Georg Schaeffler.
NU305-E-XL-M1 FAG is a single-row cylindrical roller bearing with cage. This bearing consists of a solid inner and outer ring with cylindrical rollers in a cage. This cage prevents contact between the cylinder rollers, so this bearing type can support higher speeds than full-complement cylinder roller bearings. Also, single-row cylindrical roller bearings with cages are very rigid and they can take high radial forces. As the inner and outer rings of these bearings can be easily disassembled, they are very easy to install. Applications of single-row cylindrical roller bearings include gearboxes, agricultural machinery, pumps, compressors, and electric motors.
| Model | NU305-E-XL-M1 |
| Inner Dia | 25 mm |
| Outer Dia | 62 mm |
| Width | 17 mm |
| Weight | 0.267 Kg |
| Cage Type | M- Brass Cage |
| Seal | No Seal |
